Features:

●    The whole machine is single-channel, image with audio together.

●    The management and monitoring are intelligent and on network, it has the external PC interface.

●    It has the technical data detection, monitoring systems and full-featured computer control software with auto-diagnostic function. All technical parameters can be read through the LCD display panel.

●    Comprehensive protection measures can reduce the damage of equipments. This machine has protection about no video; VSWR is too large, overheating, over-stimulus, missing phase protection and lightning protection. The switch has protection about overvoltage, over current, under voltage, over temperature, short circuit and lightning protection.

●    All power supplies are switching power supplies; high efficiency, excellent regulator range, strong adaptable from the change of the external voltage.

●    It adopts modular design concept.

●    Hot-pluggable design: power amplifier and switching power are supporting the Hot-plug, it’s easy to debug and maintenance; improve the reliability.

●    The fan is built-in the chassis, the transmitter has a compact structure and a beautiful shape.

Technical Specifications:

1.Working frequency：UHF 13~48 Channel arbitrary choice
2.Output power：     500W (Synchronous)
3.Output impedance：      50Ω
4.Inter-modulation distortion：   ≤-50dB
5.Useless transmission：In adjacent channel ≤-40dB Out adjacent channel ≤-60dB
6.RF output interface：  7/16"
7. Power supply：  Single-phase 220V
8.Size: 4U, 19-inch standard
9.Weight：  30KG

Image performance：

1.Video frequency input level： 1VP-P positive polarity
2.Video frequency input impedance：  75Ω
3.DG：    ±8%
4.DP：    ±7°
5.Luminance nonlinear：   ≤12%

Sound performance:

1.Audio input level：   0dBm±6dB
2.Audio input impedance：  10KΩ (imbalance)
3.Maximum frequency deviation：  ±50KHz
4.Harmonic distortion：     ≤1%
5.Signal-to -clutter：     ≥60dB
